Max. Resolution
1920 (H) × 1080 (V)

Scanning System
Progressive

Electronic Shutter Speed
PAL: 1/25 s–1/100000 s
NTSC: 1/30 s–1/100000 s

Min. Illumination
0.01 lux@F2.0 (Color, 30 IRE)
0.001 lux@F2.0 (B/W, 30 IRE)
0 lux (Illuminator on)

S/N Ratio
>65 dB

Illumination Distance
IR: 20 m (65.62 ft)
Warm light: 20 m (65.62 ft)

Illuminator On/Off Control
Auto

Illuminator Number
2 (Warm light);2 (IR light)

Angle Adjustment
Pan: 0°–360°
Tilt: 0°–90°
Rotation: 0°–360°

Lens
Lens Type
Fixed-focal

Auto Focus
No

Lens Mount
M12

Focal Length
2.8 mm;3.6 mm

Max. Aperture
F2.0

Field of View
2.8 mm: H: 102°; V: 60°; D: 129°
3.6 mm: H: 83°; V: 48°; D: 105°

Iris Control
Fixed

Close Focus Distance
2.8 mm: 0.5 m (1.64 ft)
3.6 mm: 0.7 m (2.30 ft)

Video
Video Frame Rate
CVI:
PAL: 1080p@25 fps;
NTSC: 1080p@30 fps;
AHD:
PAL: 1080p@25 fps;
NTSC: 1080p@30 fps;
TVI:
PAL: 1080p@25 fps;
NTSC: 1080p@30 fps;
CVBS:
PAL: 960H;
NTSC: 960H

Day/Night
Auto(ICR)/Color/B/W

BLC
BLC; HLC; DWDR

WDR
DWDR

White Balance
Auto; Area white balance

Gain Control
Auto

Noise Reduction
3D NR

Illumination Mode
Smart IR&WL; WL Mode; IR Mode

Mirror
Yes

Privacy Masking
Off/On (8 areas, rectangle)

Certification
Certifications
CE-LVD: EN 62368-1;
CE-EMC: EN 55032; EN 55035;
FCC: 47 CFR FCC Part 15, Subpart B

Port
Video Output
Video output choices of CVI/TVI/AHD/CVBS by one BNC port

Audio Input
1 channel

Power
Power Supply
12 VDC ± 30%

Power Consumption
Max 2.6W (12 VDC, IR on)

Environment
Operating Temperature
–40 °C to +60 °C (–40 °F to +140 °F)

Operating Humidity
<95% (RH), non-condensing

Storage Temperature
–40 °C to +60 °C (–40 °F to +140 °F)

Storage Humidity
<95% (RH), non-condensing

Protection
IP67

Structure
Casing Material
Plastic

Product Dimensions
163.4 mm × 69.7 mm × 70 mm (6.43″ × 2.74″ × 2.76″)

Net Weight
0.18 kg (0.40 lb)

Gross Weight
0.26 kg (0.57 lb)

Installation
Wall mount; ceiling mount; vertical pole mount
