Image Sensor
2MP CMOS

Max. Resolution
1920 (H) × 1080 (V)

Scanning System
Progressive

Electronic Shutter Speed
PAL: 1/25 s–1/100,000 s
NTSC: 1/30 s–1/100,000 s

Min. Illumination
0.04 lux/F2.0, 30 IRE, 0 lux IR on

S/N Ratio
>65 dB

Illumination Distance
20 m (65.62 ft)

Illuminator On/Off Control
Auto/Manual

Illuminator Number
2 (IR light)

Pan/Tilt/Rotation Range
Pan: 0°–360°
Tilt: 0°–90°
Rotation: 0°–360°

Lens

Lens Type
Fixed-focal

Lens Mount
M12

Focal Length
2.8 mm; 3.6 mm; 6 mm

Max. Aperture
F2.0

Field of View
2.8 mm: H: 102°; V: 54°; D: 120°
3.6 mm: H: 83°; V: 44°; D: 99°
6 mm: H: 53°; V: 30°; D: 60°

Iris Control
Fixed

Close Focus Distance
2.8 mm: 0.6 m (1.97 ft)
3.6 mm: 0.8 m (2.62 ft)
6 mm: 1.9 m (6.23 ft)

Video

Video Frame Rate
CVI:
PAL: 1080p@25 fps; 720p@25 fps
NTSC: 1080p@30 fps; 720p@30 fps
TVI:
PAL: 1080p@25 fps; 720p@25 fps
NTSC: 1080p@30 fps; 720p@30 fps
AHD:
PAL: 1080p@25 fps; 720p@25 fps
NTSC: 1080p@30 fps; 720p@30 fps
CVBS:
PAL: 960H
NTSC: 960H

Day/Night
Auto (ICR)/Color/B/W

BLC
BLC; HLC; DWDR

WDR
DWDR

White Balance
Auto; Area white balance

Gain Control
Auto/Manual

Noise Reduction
2D NR

Smart Illumination
Yes

Mirror
Yes

Privacy Masking
Off/On (8 areas, rectangle)

Certification
Certifications
CE (EN55032, EN55024, EN50130-4) FCC (CFR 47 FCC Part 15 subpartB, ANSI C63.4-2014)

Power
Power Supply
12 VDC ± 30%

Power Consumption
Max. 2.7 W (12 VDC, IR on)

Environment
Operating Temperature
–40 °C to +60 °C (–40 °F to 140 °F)

Operating Humidity
<95% (RH), non-condensing

Storage Temperature
–40 °C to +60 °C (–40 °F to +140 °F)

Protection
IP67

Structure
Casing
Plastic

Product Dimensions
149.3 mm × 69.8 mm × 69.8 mm (5.88″ × 2.75″ × 2.75″)

Packaging Dimensions
164 mm × 79 mm × 90 mm (6.46″ × 3.11″ × 3.54″)

Net Weight
0.14 kg (0.31 lb)

Gross Weight
0.17 kg (0.37 lb)

Installation
Wall mount; ceiling mount; horizontal pole mount
